Power Supply|MSI|MEG AI1600T PCIE5|ATX 3.1|1600 Watts|Efficiency 80 PLUS TITANIUM|MEGAI1600TPCIE5

Summary: MSI MEG Ai1600T PCIE5. Total power: 1600 W, AC input voltage: 100 - 240 V, Power Factor Correction (PFC) type: Active. Motherboard power connector: 24-pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Titanium. Product colour: Black, Fan diameter: 13.5 cm. Width: 190 mm, Depth: 150 mm, Height: 86 mm

Category Code: PSU

Unit Box Height: 0.25

Unit Box Length: 0.385

Unit Box Width: 0.15

AC input voltage: 100 - 240 V

Combined power (+12V): 1600 W

Combined power (+3.3V): 120 W

Combined power (+5V): 120 W

Combined power (+5Vsb): 15 W

Combined power (-12V): 3.6 W

Efficiency: 94 %

Max output current (+12V): 133.3 A

Max output current (+3.3V): 22 A

Max output current (+5V): 22 A

Max output current (+5Vsb): 3 A

Max output current (-12V): 0.3 A

Power Factor Correction (PFC) type: Active

Total power: 1600 W

Cabling type: Fully-Modular

EPS power connector (4+4 pin): Yes

EPS power connector (8-pin): No

Motherboard power connector: 24-pin ATX

Number of SATA power connectors: 8

PCI Express power connectors (16-pin): 2

PCI Express power connectors (6+2 pin): 9

Peripheral (Molex) power connectors (4-pin): 8

80 PLUS certification: 80 PLUS Titanium

Bearing technology: DBB

Power supply unit (PSU) form factor: ATX

Purpose: PC

Fan diameter: 135 mm

Product colour: Black

Depth: 150 mm

Height: 86 mm

Width: 190 mm

Model name: MEG AI1600T PCIE5

Unit Calculated Volume: 0.018942 cubm

Unit Calculated Weight: 6.4 kg

Manufacturer: MSI
