Power Supply|ADATA|XPG CORE REACTOR II|850 Watts|Efficiency 80 PLUS GOLD|COREREACTORII850G-WHCEU

Summary: XPG COREREACTOR II 850W Power Supply. Total power: 850 W, AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: White, Cooling type: Active, Fan diameter: 12 cm. Certification: CE | CB| FCC(IC) | TUV | cTUVus | TUV S-Zeichen | NOM | BSMI | UKCA | EAC | CCC | RCM

Category Code: PSU

Unit Box Height: 0.16

Unit Box Length: 0.34

Unit Box Width: 0.21

AC input frequency: 47 - 63 Hz

AC input voltage: 100 - 240 V

Input current: 12 A

Max output current (+12V): 62.5 A

Max output current (+3.3V): 22 A

Max output current (+5V): 22 A

Max output current (+5Vsb): 3 A

Max output current (-12V): 0.3 A

Power factor: 0.99

Power protection features: Over current/Over power/Over voltage/Short circuit/Surge & inrush protection (SIP)/Under voltage

Total power: 850 W

ATX power connector (12+4 pin): Y

ATX Power connector (24-pin): Y

Cabling type: Fully-Modular

EPS power connector (8-pin): Y

Motherboard power connector: 20+4 pin ATX

Number of SATA power connectors: 8

PCI Express power connectors (6+2 pin): 6

Peripheral (Molex) power connectors (4-pin): 4

80 PLUS certification: 80 PLUS Gold

ATX version: 3.0

Bearing technology: FDB

EPS version: 2.92

Mean time between failures (MTBF): 100000 h

Power supply unit (PSU) form factor: ATX

Purpose: PC

Cooling type: Active

Fan diameter: 120 mm

Number of fans: 1 fan(s)

Product colour: White

Certification: CE | CB| FCC(IC) | TUV | cTUVus | TUV S-Zeichen | NOM | BSMI | UKCA | EAC | CCC | RCM

Depth: 150 mm

Height: 86 mm

Weight: 1596 g

Width: 140 mm

Package weight: 3100 g

Model name: XPG CORE REACTOR II

Unit Calculated Volume: 0.01388 cubm

Unit Calculated Weight: 3.67 kg
