Power Supply|GIGABYTE|GP-P650G PG5|ATX|PC|100 - 240 V|650 W|GP-P650GPG5

Summary: GIGABYTE P650G PCIE 5.1 Power Supply - PCIe 5.1, 80 PLUS Silver, 120mm Fan, ATX 3.1 compatible, EU Plug. Total power: 650 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 120,500 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 140 mm, Depth: 150 mm, Height: 86 mm

Category Code: PSU

Unit Box Height: 0.12

Unit Box Length: 0.26

Unit Box Width: 0.215

AC input frequency: 50/60 Hz

AC input voltage: 100 - 240 V

Combined power (+12V): 650 W

Combined power (+3.3V): 90 W

Combined power (+5V): 650 W

Combined power (+5Vsb): 15 W

Combined power (-12V): 3.6 W

Input current: 10 - 6 A

Max output current (+12V): 54.2 A

Max output current (+3.3V): 18 A

Max output current (+5V): 18 A

Max output current (+5Vsb): 18 A

Max output current (-12V): 0.3 A

Maximum input current (@110V): 10 A

Maximum input current (@220V): 6 A

Power Factor Correction (PFC) type: Active

Power Good signal delay range: 100 - 150 ms

Power protection features: Over power/Overcharge/Short circuit/Under voltage

Total power: 650 W

ATX power connector (20+4 pin): Yes

Cabling type: Non-Modular

CPU P4 connector (4-pin): 1

CPU power cable length: 600 mm

CPU power connector (4+4 pin): Yes

Floppy disk drive connector: Yes

Motherboard power cable length: 600 mm

Motherboard power connector: 20+4 pin ATX

Number of SATA power connectors: 6

PCI Express power cable length: 500 mm

PCI Express power connectors (6+2 pin): 2

Peripheral (Molex) power cable length: 150 mm

Peripheral (Molex) power connectors (4-pin): 3

SATA power cable length: 120/500 mm

80 PLUS certification: 80 PLUS Gold

ATX version: 3.1

Bearing technology: HYB

Mean time between failures (MTBF): 100000 h

Power supply unit (PSU) form factor: ATX

Purpose: PC

Cooling type: Active

Fan diameter: 120 mm

Fan location: Top

Number of fans: 1 fan(s)

On/off switch: Yes

Product colour: Black

Depth: 150 mm

Height: 86 mm

Weight: 1760 g

Width: 140 mm

Package depth: 110 mm

Package height: 180 mm

Package type: Box

Package weight: 1920 g

Package width: 260 mm

Warranty period: 5 year(s)

Model name: GP-P650G PG5

Units per Pallet: 0

Unit Calculated Volume: 0.007986 cubm

Unit Calculated Weight: 2.15 kg
