Power Supply|ADATA|1200 Watts|Efficiency 80 PLUS GOLD|COREREACTORII1200G-BKCEU

Summary: XPG COREREACTOR II 1200W Power Supply. Total power: 1200 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Fan diameter: 13.5 cm. Compliance certificates: BSMI, CB, CE, China Compulsory Certification (CCC), EAC, Federal Communications Commission (FCC),..., Certification: CE | CB| FCC(IC) | TUV | cTUVus | TUV S-Zeichen | NOM | BSMI | UKCA | EAC | CCC | RCM

Category Code: PSU

Unit Box Height: 0.212

Unit Box Length: 0.34

Unit Box Width: 0.16

AC input frequency: 50/60 Hz

AC input voltage: 100 - 240 V

Input current: 15 A

Max output current (+12V): 100 A

Max output current (+3.3V): 22 A

Max output current (+5V): 22 A

Max output current (+5Vsb): 3 A

Max output current (-12V): 0.3 A

Power factor: 0.99

Power protection features: Over current/Over power/Over voltage/Overheating/Short circuit/Surge & inrush protection (SIP)/Under voltage

Total power: 1200 W

ATX power connector (12+4 pin): Yes

ATX Power connector (24-pin): Yes

Cabling type: Fully-Modular

EPS power connector (8-pin): Yes

Motherboard power connector: 24-pin ATX

Number of SATA power connectors: 9

PCI Express power connectors (6+2 pin): 8

Peripheral (Molex) power connectors (4-pin): 3

80 PLUS certification: 80 PLUS Gold

ATX version: 3.0

Bearing technology: FDB

EPS version: 2.92

Mean time between failures (MTBF): 100000 h

Power supply unit (PSU) form factor: ATX

Purpose: PC

Fan diameter: 135 mm

Product colour: Black

Certification: CE | CB| FCC(IC) | TUV | cTUVus | TUV S-Zeichen | NOM | BSMI | UKCA | EAC | CCC | RCM

Compliance certificates: BSMI/CB/CE/China Compulsory Certification (CCC)/cTUVus/EAC/Federal Communications Commission (FCC)/Norma Oficial Mexicana (NOM)/RCM/UKCA

Depth: 150 mm

Height: 86 mm

Width: 160 mm

Package depth: 338 mm

Package height: 157 mm

Package weight: 3430 g

Package width: 210 mm

Model name: CORE REACTOR II

Unit Calculated Volume: 0.01342 cubm

Unit Calculated Weight: 4.05 kg
