PC|DELL|Pro Micro|QCM1250|Business|Desktop|CPU Core i7|i7-14700T|1300 MHz|CPU features vPro|RAM 8GB|DDR5|5600 MHz|SSD 512GB|Windows 11 Pro|BTO009_QCM1250_EMEA_NKB

Summary: DELL Pro QCM1250. Processor family: Intel® Core™ i7, Processor model: i7-14700T. Internal memory: 8 GB, Internal memory type: DDR5-SDRAM. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics card model: Intel UHD Graphics 770. Wi-Fi. Operating system installed: Windows 11 Pro, Operating system architecture: 64-bit. Power supply: 90 W. Chassis type: Micro PC. Product type: Mini PC. Weight: 1.16 kg. Product colour: Black

Category Code: DT

Unit Box Height: 0.131

Unit Box Length: 0.5

Unit Box Width: 0.235

Cable lock slot: Yes

Cable lock slot type: Kensington

Chassis type: Micro PC

Placement supported: Horizontal/Vertical

Product colour: Black

Efficient cores: 12

Efficient-core base frequency: 0.9 GHz

Efficient-core Max Turbo Frequency: 3.7 GHz

Maximum turbo power: 106 W

Number of processors installed: 1

Performance cores: 8

Performance-core base frequency: 1.3 GHz

Performance-core Max Turbo Frequency: 5 GHz

Processor base power: 35 W

Processor boost frequency: 5.2 GHz

Processor cache: 33 MB

Processor cache type: Smart Cache

Processor cores: 20

Processor family: Intel® Core™ i7

Processor generation: Intel® Core™ i7 (14th gen)

Processor manufacturer: Intel

Processor model: i7-14700T

Processor threads: 28

AI software frameworks supported by NPU: DirectML/ONNX RT/OpenVINO/WebNN/Windows ML

Internal memory: 8 GB

Internal memory type: DDR5-SDRAM

Maximum internal memory: 64 GB

Memory channels: Single-channel

Memory data transfer rate: 4800 MT/s

Memory layout (slots x size): 1 x 8 GB

Memory slots: 2x SO-DIMM

Non-ECC: Yes

Number of SSDs installed: 1

Number of storage drives installed: 1

NVMe: Yes

Optical drive type: No

SSD Capacity: 512 GB

SSD form factor: M.2

SSD interface: PCI Express 4.0

Storage media: SSD

Total SSDs capacity: 512 GB

Total storage capacity: 512 GB

Discrete graphics card: No

Discrete graphics card model: Not available

On-board GPU manufacturer: Intel

On-board graphics card: Yes

On-board graphics card family: Intel® UHD Graphics

On-board graphics card model: Intel UHD Graphics 770

Antenna type: 2x2

Bluetooth: Yes

Cabling technology: 10/100/1000Base-T(X)

Ethernet LAN: Yes

Ethernet LAN data rates: 10/100/1000 Mbit/s

LAN controller: Intel WGI219LM

Top Wi-Fi standard: Wi-Fi 6E (802.11ax)

Wi-Fi: Yes

Wi-Fi standards: 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6E (802.11ax)

WLAN controller manufacturer: Intel

WLAN controller model: Intel Wi-Fi 6E AX211

Combo headphone/mic port: Yes

DC-in jack: Yes

DisplayPort version: 1.4a

DisplayPorts quantity: 1

Ethernet LAN (RJ-45) ports: 1

HDMI ports quantity: 1

HDMI version: 2.1

Number of front audio ports: 1

Number of front USB ports: 2

Number of rear USB ports: 4

USB 2.0 ports quantity: 2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1

Audio chip: Realtek ALC3204

Audio system: High Definition Audio

Market positioning: Business

Motherboard chipset: Intel Q870

Product Type: Mini PC

Trusted Platform Module (TPM): Yes

Trusted Platform Module (TPM) version: 2.0

Operating system architecture: 64-bit

Operating system installed: Windows 11 Pro

Power supply: 90 W

Power supply input frequency: 50 / 60 Hz

Power supply input voltage: 100 - 240 V

Non-operating altitude: -15.2 - 10668 m

Non-operating shock: 105 g

Non-operating vibration: 1.37 g

Operating altitude: -15.2 - 3048 m

Operating relative humidity (H-H): 20 - 80 %

Operating shock: 40 g

Operating temperature (T-T): 10 - 35 °C

Operating vibration: 0.26 g

Storage relative humidity (H-H): 5 - 95 %

Storage temperature (T-T): -40 - 65 °C

Sustainability certificates: ENERGY STAR/EPEAT Climate +/EPEAT Gold

Depth: 178 mm

Height: 182 mm

Weight: 1160 g

Width: 36 mm

Keyboard included: No

Display included: No

Desktop Computer Family name: Pro Micro

Unit Calculated Volume: 0.0153925 cubm

Unit Calculated Weight: 2.26 kg
