PC|DELL|Pro Max Micro|FCM2250|Business|Desktop|CPU Core Ultra|u7-265|2400 MHz|RAM 32GB|DDR5|5600 MHz|SSD 1TB|Graphics card NVIDIA RTX A1000|8GB|Windows 11 Pro|BTO107_FCM2250_EMEA

Summary: DELL Pro Max FCM2250. Processor family: Intel Core Ultra 7, Processor model: 265U. Internal memory: 32 GB, Internal memory type: DDR5-SDRAM. Total storage capacity: 1 TB, Storage media: SSD. On-board graphics card model: Intel Graphics, Discrete graphics card model: NVIDIA RTX A1000. Operating system installed: Windows 11 Pro, Operating system architecture: 64-bit. Power supply: 280 W. Chassis type: Micro PC. Product type: PC. Weight: 2.54 kg. Product colour: Black

Category Code: DT

Unit Box Height: 0.21

Unit Box Length: 0.6

Unit Box Width: 0.27

Cable lock slot: Yes

Cable lock slot type: Kensington

Chassis type: Micro PC

Intel® vPro™ Platform Eligibility: Yes

Product colour: Black

Efficient cores: 8

Efficient-core base frequency: 1.7 GHz

Efficient-core Max Turbo Frequency: 4.2 GHz

Low Power Efficient-core Base Frequency: 700 MHz

Low Power Efficient-core Max Turbo Frequency: 2.4 GHz

Low Power Efficient-cores: 2

Maximum turbo power: 57 W

Number of processors installed: 1

Performance cores: 2

Performance-core base frequency: 2.1 GHz

Performance-core Max Turbo Frequency: 5.3 GHz

Processor base power: 15 W

Processor boost frequency: 5.3 GHz

Processor cache: 12 MB

Processor cores: 12

Processor family: Intel Core Ultra 7

Processor generation: Intel Core Ultra (Series 2)

Processor manufacturer: Intel

Processor model: 265U

Processor threads: 14

AI software frameworks supported by NPU: DirectML/ONNX RT/OpenVINO/WebNN/Windows ML

Neural processor unit (NPU): Intel AI Boost

Sparsity support: Yes

Windows Studio effects support: Yes

Internal memory: 32 GB

Internal memory type: DDR5-SDRAM

Maximum internal memory: 64 GB

Memory channels: Single-channel

Memory data transfer rate: 5600 MT/s

Memory layout (slots x size): 1 x 32 GB

Memory slots: 2x SO-DIMM

Non-ECC: Yes

M.2 SSD size: 2280 (22 x 80 mm)

Number of SSDs installed: 1

Number of storage drives installed: 1

Number of storage drives supported: 2

NVMe: Yes

Optical drive type: No

SSD Capacity: 1000 GB

SSD form factor: M.2

SSD interface: PCI Express 4.0

SSD memory type: TLC

Storage media: SSD

Total SSDs capacity: 1000 GB

Total storage capacity: 1000 GB

Discrete GPU manufacturer: NVIDIA

Discrete graphics card: Yes

Discrete graphics card memory: 8 GB

Discrete graphics card model: NVIDIA RTX A1000

Discrete graphics memory type: GDDR6

Graphics card Mini DisplayPort ports quantity: 4

Number of discrete graphics cards: 1

On-board GPU manufacturer: Intel

On-board graphics card: Yes

On-board graphics card family: Intel Graphics

On-board graphics card model: Intel Graphics

Antenna type: 2x2

Bluetooth: Yes

Cabling technology: 10/100/1000Base-T(X)

Ethernet LAN: Yes

Ethernet LAN data rates: 10/100/1000 Mbit/s

LAN controller: Intel® I219-LM

Top Wi-Fi standard: Wi-Fi 7 (802.11be)

Wi-Fi: Yes

Wi-Fi standards: 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6E (802.11ax)/Wi-Fi 7 (802.11be)

WLAN controller manufacturer: Intel

WLAN controller model: Intel Wi-Fi 7 BE200

Combo headphone/mic port: Yes

DC-in jack: Yes

DisplayPort version: 1.4a

DisplayPorts quantity: 3

Ethernet LAN (RJ-45) ports: 1

Number of front audio ports: 1

Number of front USB ports: 3

Number of rear USB ports: 5

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1

USB 3.2 Gen 2x2 Type-C ports quantity: 1

Audio chip: Realtek ALC3204

Audio system: High Definition Audio

Market positioning: Business

Motherboard chipset: Intel W880

Product Type: PC

Trusted Platform Module (TPM): Yes

Trusted Platform Module (TPM) version: 2.0

Operating system architecture: 64-bit

Operating system installed: Windows 11 Pro

Trial software: McAfee Business Protection 1-year,No Microsoft Office License included (Fed and Premier, Exception Only)

Power supply: 280 W

Power supply input frequency: 50 / 60 Hz

Power supply input voltage: 100 - 240 V

Non-operating altitude: -15.2 - 10668 m

Non-operating shock: 160 g

Non-operating vibration: 1.3 g

Operating altitude: -15.2 - 3048 m

Operating relative humidity (H-H): 10 - 90 %

Operating shock: 110 g

Operating temperature (T-T): 0 - 35 °C

Operating vibration: 0.66 g

Storage relative humidity (H-H): 0 - 95 %

Storage temperature (T-T): -40 - 65 °C

Sustainability certificates: ENERGY STAR/EPEAT Climate +/EPEAT Gold

Depth: 178 mm

Height: 206 mm

Weight: 2540 g

Width: 79.3 mm

Carbon emissions, end-of-life (kg of CO2e): 1.28

Carbon emissions, energy usage (kg of CO2e): 114.741

Carbon emissions, logistics (kg of CO2e): 3.66

Carbon emissions, manufacturing (kg of CO2e): 63.318

Display included: No

PAIA version: GaBi version 1, 2024

Total carbon footprint (kg of CO2e): 183

Desktop Computer Family name: Pro Max Micro

Unit Calculated Volume: 0.03402 cubm

Unit Calculated Weight: 4.07 kg
