Notebook|LENOVO|CPU AMD RyzenT 5|220|3.5 GHz|15.6 "|1920 x 1080 pixels|RAM 16 GB|DDR5-SDRAM|SSD 512 GB|Discrete graphics NVIDIA GeForce RTX 5050|8 GB|On-board graphics Yes|Numeric keypad Yes|Keyboard language English|Colour Grey|Weight 2.4 kg|5600 MHz|83JG003DPB

Summary: Lenovo LOQ 15AHP10. Product type: Laptop, Form factor: Clamshell. Processor family: AMD Ryzen™ 5, Processor model: 220, Processor frequency: 3.5 GHz. Display diagonal: 39.6 cm (15.6"), HD type: Full HD, Display resolution: 1920 x 1080 pixels. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics card model: AMD Radeon 740M, Discrete graphics card model: NVIDIA GeForce RTX 5050. Product colour: Grey

Category Code: NB

Unit Box Height: 0.08

Unit Box Length: 0.54

Unit Box Width: 0.34

L2 cache: 6 MB

L3 cache: 16 MB

Processor base power: 28 W

Processor boost frequency: 4.9 GHz

Processor cache type: L2 & L3

Processor cores: 6

Processor family: AMD Ryzen™ 5

Processor frequency: 3.5 GHz

Processor generation: AMD Ryzen 200 Series

Processor manufacturer: AMD

Processor model: 220

Processor threads: 12

Anti-glare screen: Yes

Colour gamut: 100 %

Contrast ratio (typical): 1000:1

Display brightness: 300 cd/m²

Display diagonal: 15.6 "

Display resolution: 1920 x 1080 pixels

HD type: Full HD

LED backlight: Yes

Maximum refresh rate: 144 Hz

Native aspect ratio: 16:9

Panel type: IPS

RGB colour space: sRGB

Touchscreen: No

Colour name: Luna Grey

Form Factor: Clamshell

Housing material: Acrylonitrile butadiene styrene (ABS),Polycarbonate (PC)

Product colour: Grey

Product Type: Laptop

Neural processor unit (NPU): No

Internal memory: 16 GB

Internal memory type: DDR5-SDRAM

Maximum internal memory: 32 GB

Memory channels: Dual-channel

Memory clock speed: 5600 MHz

Memory form factor: SO-DIMM

Memory layout (slots x size): 1 x 16 GB

Memory slots: 2x SO-DIMM

Card reader integrated: No

M.2 SSD size: 2242 (22 x 42 mm)

Number of SSDs installed: 1

NVMe: Yes

Optical drive type: No

SSD Capacity: 512 GB

SSD form factor: M.2

SSD interface: PCI Express 4.0

Storage media: SSD

Total SSDs capacity: 512 GB

Total storage capacity: 512 GB

Discrete GPU manufacturer: NVIDIA

Discrete graphics card: Yes

Discrete graphics card memory: 8 GB

Discrete graphics card model: NVIDIA GeForce RTX 5050

Discrete graphics memory type: GDDR7

NVIDIA G-SYNC: Yes

On-board GPU manufacturer: AMD

On-board graphics card: Yes

On-board graphics card family: AMD Radeon

On-board graphics card model: AMD Radeon 740M

Audio chip: Realtek ALC3287

Audio system: Nahimic Audio

Built-in microphone: Yes

Number of built-in speakers: 2

Number of microphones: 2

Speaker power: 2 W

Front camera: Yes

Front camera resolution (numeric): 5 MP

Privacy camera: Yes

Privacy type: Privacy shutter

Antenna type: 2x2

Bluetooth: Yes

Bluetooth version: 5.3

Ethernet LAN: Yes

Ethernet LAN data rates: 100/1000 Mbit/s

Mobile network connection: No

Top Wi-Fi standard: Wi-Fi 6 (802.11ax)

Wi-Fi standards: Wi-Fi 6 (802.11ax)

WWAN: Not installed

Combo headphone/mic port: Yes

Ethernet LAN (RJ-45) ports: 1

HDMI ports quantity: 1

HDMI version: 2.1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1

USB Type-C DisplayPort Alternate Mode: Yes

Motherboard chipset: AMD SoC

Copilot key: Yes

Keyboard backlit: Yes

Keyboard backlit colour: White

Keyboard language: English

Numeric keypad: Yes

Pointing device: Touchpad

Operating system installed: No

Battery capacity: 60 Wh

Battery life (max): 4.4 h

Battery technology: Lithium-Ion (Li-Ion)

Continuous video playback time: 10.4 h

Fast charging: Yes

Fast charging time (50%): 30 min

AC adapter frequency: 50/60 Hz

AC adapter input voltage: 100 - 240 V

AC adapter power: 170 W

USB Power Delivery (USB PD): Yes

USB Type-C charging port: Yes

Fingerprint reader: No

Password protection: Yes

Password protection type: BIOS/HDD/Power on/User

Trusted Platform Module (TPM): Yes

Trusted Platform Module (TPM) version: 2.0

Maximum shipping altitude: 3048 m

Operating relative humidity (H-H): 8 - 95 %

Operating temperature (T-T): 5 - 35 °C

Storage relative humidity (H-H): 5 - 95 %

Storage temperature (T-T): 5 - 43 °C

Certification: ErP Lot 6/26 RoHS compliant TÜV Rheinland Low Blue Light (Software Solution)

Compliance certificates: RoHS

Sustainability certificates: ErP

Depth: 258.7 mm

Height (front): 21.9 mm

Height (rear): 23.9 mm

Weight: 2400 g

Width: 359.86 mm

AC adapter included: Yes

Units per Pallet: 0

Unit Calculated Volume: 0.01469 cubm

Unit Calculated Weight: 3.56 kg

Manufacturer: LENOVO
