Notebook|DELL|Pro Max|14|MC14250|CPU Core Ultra|u7-265H|14"|RAM 16GB|DDR5|7500 MHz|SSD 512GB|NVIDIA RTX PRO 500|8GB|NOR|Smart Card Reader|Windows 11 Pro|1.83 kg|BTO120_MC14250_EMEA_NOR

Summary: DELL Pro Max 14 MC14250. Product type: Mobile workstation, Form factor: Clamshell. Processor family: Intel Core Ultra 7, Processor model: 265H. Display diagonal: 35.6 cm (14"), HD type: Full HD+, Display resolution: 1920 x 1200 pixels. Internal memory: 16 GB, Internal memory type: LPDDR5x-SDRAM. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics card model: Intel Arc 140T. Operating system installed: Windows 11 Pro. Product colour: Black. Weight: 1.83 kg

Category Code: NB

Unit Box Height: 0.35

Unit Box Length: 0.42

Unit Box Width: 0.062

Efficient cores: 8

Efficient-core base frequency: 1.7 GHz

Efficient-core Max Turbo Frequency: 4.5 GHz

Low Power Efficient-core Base Frequency: 700 MHz

Low Power Efficient-core Max Turbo Frequency: 2.5 GHz

Low Power Efficient-cores: 2

Maximum turbo power: 115 W

Performance cores: 6

Performance-core base frequency: 2.2 GHz

Performance-core Max Turbo Frequency: 5.3 GHz

Processor base power: 28 W

Processor boost frequency: 5.3 GHz

Processor cache: 24 MB

Processor cores: 16

Processor family: Intel Core Ultra 7

Processor generation: Intel Core Ultra (Series 2)

Processor manufacturer: Intel

Processor model: 265H

Processor threads: 16

Anti-glare screen: Yes

Colour gamut: 45 %

Contrast ratio (typical): 800:1

Display brightness: 300 cd/m²

Display diagonal: 14 "

Display resolution: 1920 x 1200 pixels

Display response rise/fall: 35 ms

HD type: Full HD+

LED backlight: Yes

Maximum refresh rate: 60 Hz

Native aspect ratio: 16:10

Panel type: WVA

Pixel density: 162 ppi

RGB colour space: NTSC

Touchscreen: No

Form Factor: Clamshell

Product colour: Black

Product Type: Mobile workstation

AI software frameworks supported by NPU: DirectML/ONNX RT/OpenVINO/WebNN/Windows ML

GPU performance up to: 75 TOPs

Neural processor unit (NPU): Intel AI Boost

NPU performance up to: 13 TOPs

Sparsity support: Yes

Total processor performance up to: 97 TOPs

Windows Studio effects support: Yes

Internal memory: 16 GB

Internal memory type: LPDDR5x-SDRAM

Maximum internal memory: 64 GB

Memory channels: Dual-channel

Memory data transfer rate: 7467 MT/s

Memory layout (slots x size): 1 x 16 GB

Non-ECC: Yes

M.2 SSD size: 2230 (22 x 30 mm)

Number of SSDs installed: 1

NVMe: Yes

Optical drive type: No

SSD Capacity: 512 GB

SSD form factor: M.2

SSD interface: PCI Express 4.0

SSD performance class: 35

Storage media: SSD

Total SSDs capacity: 512 GB

Total storage capacity: 512 GB

On-board GPU manufacturer: Intel

On-board graphics card: Yes

On-board graphics card family: Intel Arc Graphics

On-board graphics card model: Intel Arc 140T

Audio chip: Realtek ALC3329

Audio system: MaxxAudio Pro

Built-in microphone: Yes

Number of built-in speakers: 2

Number of microphones: 2

Speaker power: 2 W

Speakers manufacturer: Waves

Front camera: Yes

Front camera HD type: Full HD

Front camera resolution: 1920 x 1080 pixels

Front camera resolution (numeric): 2.07 MP

Infrared (IR) camera: Yes

Privacy camera: Yes

Privacy type: Privacy shutter

Video capturing speed: 30 fps

Antenna type: 2x2

Bluetooth: Yes

Ethernet LAN: Yes

Ethernet LAN data rates: 10/100/1000 Mbit/s

Mobile network connection: No

Top Wi-Fi standard: Wi-Fi 7 (802.11be)

Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz)

Wi-Fi data rate (max): 5760 Mbit/s

Wi-Fi standards: 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6E (802.11ax)/Wi-Fi 7 (802.11be)

WLAN controller manufacturer: Intel

WLAN controller model: Intel Wi-Fi 7 BE201

Combo headphone/mic port: Yes

Ethernet LAN (RJ-45) ports: 1

HDMI ports quantity: 1

HDMI version: 2.1

Intel® Thunderbolt 4: Yes

PowerShare: Yes

Thunderbolt 4 ports quantity: 2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2

USB Type-C DisplayPort Alternate Mode: Yes

Accelerometer: Yes

Hall sensor: Yes

Motherboard chipset: Intel SoC

Copilot key: Yes

Keyboard backlit: Yes

Numeric keypad: No

Pointing device: Touchpad

Operating system architecture: 64-bit

Operating system installed: Windows 11 Pro

Brand specific technologies: Control Vault 3+,Express Charge Boost capable

Battery capacity: 72 Wh

Battery recharge time: 3 h

Battery technology: Lithium Polymer (LiPo)

Battery voltage: 15.6 V

Battery weight: 270 g

Fast charging: Yes

Number of battery cells: 4

AC adapter frequency: 50/60 Hz

AC adapter input voltage: 100 - 240 V

AC adapter power: 130 W

USB Power Delivery (USB PD): Yes

USB Type-C charging port: Yes

USB Type-C required charging power (max): 71 W

USB Type-C required charging power (min): 45 W

Cable lock slot: Yes

Cable lock slot type: Wedge

Fingerprint reader: Yes

Smart Card Reader: Yes

Trusted Platform Module (TPM): Yes

Trusted Platform Module (TPM) version: 2.0

Windows Hello: Yes

Non-operating altitude: -15.2 - 10668 m

Non-operating shock: 160 g

Non-operating vibration: 1.3 g

Operating altitude: -15.2 - 3048 m

Operating relative humidity (H-H): 10 - 90 %

Operating shock: 110 g

Operating temperature (T-T): 0 - 35 °C

Operating vibration: 0.66 g

Storage relative humidity (H-H): 0 - 95 %

Storage temperature (T-T): -40 - 65 °C

Sustainability certificates: ENERGY STAR/EPEAT Climate +/EPEAT Gold

Depth: 227.3 mm

Height (front): 14.79 mm

Height (rear): 18.9 mm

Weight: 1830 g

Width: 313 mm

AC adapter included: Yes

NB Family name: Pro Max

Model name: 14

Units per Pallet: 0

Unit Calculated Volume: 0.009114 cubm

Unit Calculated Weight: 3 kg
