Mainboard|MSI|Intel Z890|LGA 1851 (Socket V1)|ATX|RAM DDR5-SDRAM|4xSlots|Wi-Fi Yes|Bluetooth Yes|3xNumber of M.2 (M) slots|Z890GAMINGWIFI

Summary: MSI Z890 GAMING WIFI. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core Ultra (Series 2). Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, LAN controller: Realtek RTL8125D, Top Wi-Fi standard: Wi-Fi 7 (802.11be). Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: Intel

Category Code: MBI

Unit Box Height: 0.07

Unit Box Length: 0.34

Unit Box Width: 0.27

Audio chip: Realtek ALC897

Audio output channels: 7.1 channels

Component for: PC

Motherboard chipset: Intel Z890

Motherboard chipset family: Intel

Motherboard form factor: ATX

Product colour: Black

Windows operating systems supported: Windows 11

Compatible processor series: Intel Core Ultra (Series 2)

Processor manufacturer: Intel

Processor socket: LGA 1851 (Socket V1)

Supported processor sockets: LGA 1851

ECC сompatibility: Non-ECC

Maximum internal memory: 256 GB

Memory channels: Dual-channel

Memory slots type: DIMM

Number of memory slots: 4

Supported memory clock speed (max): 8800 MHz

Supported memory clock speeds: 4800/5600/6400/7200/8800 MHz

Supported memory types: DDR5-SDRAM

Number of HDDs supported: 7

Number of storage drives supported: 4

RAID levels: 0/1/10/5

RAID support: Yes

Supported storage drive interfaces: M.2,SATA III

Supported storage drive types: HDD & SSD

On-board graphics card: No

ATX Power connector (24-pin): Yes

EPS power connector (8-pin): Yes

Number of EPS power connectors (8-pin): 1

Number of SATA III connectors: 4

Total number of SATA connectors: 4

USB 2.0 connectors: 4

USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2

USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1

DisplayPort version: 1.4

DisplayPorts quantity: 1

Ethernet LAN (RJ-45) ports: 1

HDMI ports quantity: 1

HDMI version: 2.1

Thunderbolt ports quantity: 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1

Bluetooth: Yes

Bluetooth version: 5.4

Ethernet interface type: 2.5 Gigabit Ethernet

Ethernet LAN: Yes

LAN controller: Realtek RTL8125D

Top Wi-Fi standard: Wi-Fi 7 (802.11be)

Wi-Fi: Yes

Wi-Fi standards: 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)/Wi-Fi 7 (802.11be)

WLAN controller model: Killer Wi-Fi 7 BE1750

1st M.2 highest PCI Express generation: 5.0

1st M.2 largest key size: 2280

2nd M.2 highest PCI Express generation: 4.0

2nd M.2 largest key size: 2280

3rd M.2 highest PCI Express generation: 4.0

3rd M.2 largest key size: 2280

Number of M.2 (M) slots: 3

PCI Express x1 (Gen 4.x) slots: 1

PCI Express x16 (Gen 5.x) slots: 1

PCI Express x4 (Gen 4.x) slots: 2

ACPI version: 6.5

BIOS memory size: 256 Mbit

BIOS type: UEFI AMI

System Management BIOS (SMBIOS) version: 3.7

Depth: 304.8 mm

Width: 243.84 mm

Units per Pallet: 0

Unit Calculated Volume: 0.008014 cubm

Unit Calculated Weight: 1.9 kg
