Mainboard|MSI|AMD B850|SAM5|Micro-ATX|Memory DDR5|Memory slots 4|1xPCI-Express 4.0 4x |1xPCI-Express 4.0 8x|1xPCI-Express 4.0 16x|1xPCI-Express 5.0 16x|3xM.2|1xHDMI|3xUSB 2.0|4xUSB 3.2|2xUSB-C|1xOptical S/PDIF|1xRJ45|2xAudio port|MAGB850MMORTARWIFI
SKU: MAG B850M MORTAR WIFI
€ 231.06
Pieejams : 30 gab.
AMD B850
micro ATX
Audio 7.1 channels
CPU AMD
Socket Socket AM5
Series AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series
Supported memory types DDR5-SDRAM
4xNumber of memory slots
Memory slots type DIMM
Supported storage drive interfaces M.2
4xUSB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3xUSB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2xUSB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1xEthernet LAN (RJ-45) ports
1xHDMI ports quantity
Wi-Fi Yes
Bluetooth Yes
-
Category Code: MBA
-
Unit Box Height: 0.07
-
Unit Box Length: 0.282
-
Unit Box Width: 0.271
-
PCI-Express 4.0 4x : 1
-
PCI-Express 4.0 8x: 1
-
PCI-Express 4.0 16x: 1
-
PCI-Express 5.0 16x: 1
-
M.2: 3
-
HDMI: 1
-
USB 2.0: 3
-
USB 3.2: 4
-
USB-C: 2
-
Optical S/PDIF: 1
-
RJ45: 1
-
Audio port: 2
-
SATA: Yes
-
USB-C: Yes
-
USB 2.0: Yes
-
USB 3.2: Yes
-
Bluetooth: Yes
-
WiFi: Yes
-
Model: MAG B850M MORTAR WIFI
-
Chipset: AMD B850
-
Socket: SAM5
-
Form Factor: Micro-ATX
-
Memory type: DDR5
-
Frequency speed: 4800/5600/6400/8200 MHz
-
Memory slots: 4
-
Integrated video: Depending on CPU
-
Integrated audio: Realtek ALC4080
-
Integrated LAN: 5 Gigabit
-
RAID: SATA 0, 1, 10; NVMe 0, 1, 5
-
TPM: Header
-
Unit Calculated Volume: 0.006439 cubm
-
Product Net Weight: 0.8 kg
-
Unit Calculated Weight: 1.93 kg
-
Manufacturer: MSI
