Mainboard|GIGABYTE|Intel B760 Express|LGA1700|Micro-ATX|Memory DDR4|Memory slots 4|2xPCI-Express 3.0 1x|1xPCI-Express 4.0 16x|2xM.2|1x15pin D-sub|1xHDMI|1xDisplayPort|6xUSB 2.0|5xUSB 3.2|1xUSB-C|1xPS/2|1xRJ45|3xAudio port|B760MD3HPDDR4
SKU: B760M D3HP DDR4
€ 96.74
Pieejams : 1 gab.
Intel B760 Express
micro ATX
Audio 7.1 channels
CPU Intel
Socket LGA 1700
Series Intel® Celeron®/Intel® Core™ i3/Intel® Core™ i5/Intel® Core™ i7/Intel® Core™ i9/Intel® Pentium® Gold
Supported memory types DDR4-SDRAM
4xNumber of memory slots
Memory slots type DIMM
Supported storage drive interfaces M.2,SATA III
4096 x 2304 pixels
2xUSB 2.0 ports quantity
3xUSB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1xEthernet LAN (RJ-45) ports
1xVGA (D-Sub) ports quantity
1xHDMI ports quantity
-
Category Code: MBI
-
Unit Box Height: 0.275
-
Unit Box Length: 0.27
-
Unit Box Width: 0.055
-
M.2: 2
-
PCI-Express 3.0 1x: 2
-
PCI-Express 4.0 16x: 1
-
15pin D-sub: 1
-
Audio port: 3
-
DisplayPort: 1
-
HDMI: 1
-
PS/2: 1
-
RJ45: 1
-
USB 2.0: 6
-
USB 3.2: 5
-
USB-C: 1
-
SATA: Yes
-
USB 2.0: Yes
-
USB 3.2: Yes
-
USB-C: Yes
-
Model: B760M D3HP DDR4
-
Chipset: Intel B760 Express
-
Socket: LGA1700
-
Form Factor: Micro-ATX
-
Memory type: DDR4
-
Frequency speed: 2133/2400/2666/2933/3000/3200/3300/3333/3400/3466/3666/3733/3800/3866/4000/4133/4266/4300/4400/4500/4600/4700/4800/4933/5000/5133/5333 MHz
-
Memory slots: 4
-
Integrated video: Depending on CPU
-
Integrated LAN: Gigabit
-
Integrated audio: Yes
-
RAID: SATA 0, 1, 5, 10
-
TPM: Header
-
Unit Calculated Volume: 0.004836 cubm
-
Product Net Weight: 0.7 kg
-
Unit Calculated Weight: 0.993 kg
-
Manufacturer: GIGABYTE
