Mainboard|ASUS|Intel B860 Express|LGA1851|Micro-ATX|Memory DDR5|Memory slots 4|1xPCI-Express 4.0 1x|1xPCI-Express 4.0 16x|1xPCI-Express 5.0 16x|2xM.2|1xHDMI|1xDisplayPort|7xUSB 2.0|1xUSB-C|1xUSB-C w/Thunderbolt|1xOptical S/PDIF|1xRJ45|3xAudio port|PRIMEB860M-AWIFI
SKU: PRIME B860M-A WIFI
€ 201.67
Pieejams : 10 gab.
Intel B860
micro ATX
Audio 7.1 channels
CPU Intel
Socket LGA 1851 (Socket V1)
Series Intel Core Ultra (Series 2)
Supported memory types DDR5-SDRAM
4xNumber of memory slots
Memory slots type DIMM
Supported storage drive interfaces M.2,SATA III
4xUSB 2.0 ports quantity
2xUSB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1xUSB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1xEthernet LAN (RJ-45) ports
1xHDMI ports quantity
Wi-Fi Yes
Bluetooth Yes
Antenna included Yes
-
Category Code: MBI
-
Unit Box Height: 0.276
-
Unit Box Length: 0.28
-
Unit Box Width: 0.07
-
M.2: 2
-
PCI-Express 4.0 16x: 1
-
PCI-Express 4.0 1x: 1
-
PCI-Express 5.0 16x: 1
-
Audio port: 3
-
DisplayPort: 1
-
HDMI: 1
-
Optical S/PDIF: 1
-
RJ45: 1
-
USB 2.0: 7
-
USB-C: 1
-
USB-C w/Thunderbolt: 1
-
Bluetooth: Yes
-
Thunderbolt: Yes
-
USB 2.0: Yes
-
USB-C: Yes
-
WiFi: Yes
-
Model: PRIME B860M-A WIFI
-
Chipset: Intel B860 Express
-
Socket: LGA1851
-
Form Factor: Micro-ATX
-
Memory type: DDR5
-
Frequency speed: 8666 MHz
-
Memory slots: 4
-
Integrated video: Depending on CPU
-
Integrated LAN: 2.5 Gigabit
-
Integrated audio: Yes
-
RAID: SATA 0, 1, 5, 10
-
Included Accessories: Cables 2 x SATA 6Gb/s cables Miscellaneous 1 x ASUS WiFi Q-Antenna 1 x M.2 rubber package 1 x Screw package for M.2 SSD Documentation 1 x Quick start guide
-
Unit Calculated Volume: 0.00622 cubm
-
Product Net Weight: 1 kg
-
Unit Calculated Weight: 1.48 kg
-
Manufacturer: ASUS
