LCD Monitor|DAHUA|23.8 "|1920 x 1080 pixels|Full HD|Native aspect ratio 16:9|LED|Flat|DHI-LM24-A221Y

Summary: Dahua Technology LM24-A221Y. Display diagonal: 60.5 cm (23.8"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black

Category Code: LC3

Backlight type: Edge LED

Colour depth: 6 bit

Colour gamut standard: NTSC

Contrast ratio (typical): 1200:1

Display brightness (typical): 250 cd/m²

Display diagonal: 23.8 "

Display diagonal (metric): 61 cm

Display resolution: 1920 x 1080 pixels

Display technology: LED

Haze rate: 25 %

HD type: Full HD

LED backlight: Yes

Maximum refresh rate: 144 Hz

Native aspect ratio: 16:9

NTSC coverage (typical): 72 %

Panel type: IPS

Pixel density: 92.56 ppi

Pixel pitch: 0.2745 x 0.2745 mm

Response time (MPRT): 1 ms

Screen shape: Flat

Supported graphics resolutions: 1920 x 1080 (HD 1080)

Supported video modes: 1080p

Surface hardness: 3H

Touchscreen: No

Viewable size, horizontal: 527.04 mm

Viewable size, vertical: 296.46 mm

Viewing angle, horizontal: 178 °

Viewing angle, vertical: 178 °

AMD FreeSync: No

Flicker-free technology: Yes

NVIDIA G-SYNC: No

Built-in camera: No

Built-in speaker(s): No

Feet colour: Black

Front bezel colour: Black

Illuminated stand: No

Market positioning: Consumer

Product colour: Black

Built-in USB hub: No

HDMI: Yes

HDMI ports quantity: 1

HDMI version: 1.4

VGA (D-Sub) ports quantity: 1

Bluetooth: No

Wi-Fi: No

LED indicators: Status

Panel mounting interface: 100 x 100 mm

Plug and Play: Yes

Tilt adjustment: Yes

Tilt angle range: -5 - 20 °

VESA mounting: Yes

Wall mountable: Yes

AC adapter output voltage: 12 V

Energy consumption (SDR) per 1000 hours: 13 kWh

Energy efficiency class (HDR): Not available

Energy efficiency class (SDR): D

Energy efficiency scale: A to G

Power consumption (max): 22 W

Power consumption (off): 0.3 W

Power consumption (standby): 0.5 W

Power consumption (typical): 21.2 W

Power supply type: External

Operating relative humidity (H-H): 10 - 85 %

Operating temperature (T-T): 0 - 40 °C

Storage relative humidity (H-H): 5 - 90 %

Storage temperature (T-T): -20 - 60 °C

Bezel width (bottom): 16.8 mm

Bezel width (side): 3.6 mm

Bezel width (top): 2.3 mm

Depth (with stand): 189 mm

Depth (without stand): 47.6 mm

Height (with stand): 418.3 mm

Height (without stand): 322.4 mm

Weight (without stand): 2800 g

Width (with stand): 542.1 mm

Width (without stand): 542.1 mm

Package depth: 120 mm

Package height: 412 mm

Package weight: 3900 g

Package width: 602 mm

Cables included: HDMI

Manual: Yes

Power adapter included: Yes

Quick start guide: Yes

Stand included: Yes

Automatic brightness control: No

Compliance certificates: CE/Electromagnetic Compatibility (EMC)/Low Voltage Directive (LVD)

Data Sheet (Link): https://eprel.ec.europa.eu/api/product/2452512/fiches?language=EN

Energy efficiency class: D

EPREL Registration Number: 2452512

EPREL Version Number: 2

Unit Calculated Volume: 0.00832 cubm

Unit Calculated Weight: 3.9 kg

Manufacturer: DAHUA
